Ridisc Media Tests

May 17,2005 0

19. NEC ND-3520A ( fw 1.04)

Review Pages

1. Introduction
2. 4X DVD+R ( RICOHJPNR01)
3. DVD-R 4X ( RITEK G04)
4. DVD-R 8X ( TTG02)
5. DVD-R 8X ( RITEK G05)
6. DVD-R 8X Silver Printable( CMC MAG AE1)
7. DVD+R 16X ( CMC MAG M01)
8. Aopen DUW1608-ARR (fw A070)
9. Asus DRW-1604P (fw 1.18)
10. Asus DRW-1608P (fw 1.50)
11. BenQ DW1620 (fw B7U9)
12. BenQ DW1625 (fw BBEA)
13. HP DVD640i (fw ES04)
14. LG GSA-4120B (fw A116)
15. LG GSA-4163B (fw A104)
16. LG GSA-5160B (fw A303)
17. LiteOn SOHW-1653S (fw CS0K)
18. LiteOn SOHW-1673S (fw JS05)
19. NEC ND-3520A ( fw 1.04)
20. NEC ND-3530A (fw 2.10)
21. Philips DVDR16LS (fw P1.6)
22. Philips DVDRW1640P (fw P.3.4)
23. Pioneer DVR-107 (fw 1.21)
24. Pioneer DVR-108 (fw 1.19)
25. Pioneer DVR-109 (fw 1.40)
26. Plextor PX-712A (fw 1.06)
27. Plextor PX-716A (fw 1.06)
28. Ricoh MP5316DA (fw 2B.9)
29. Samsung TS-H552B (fw TS09)
30. Toshiba SD-R5372 (fw TU55)
31. Waitec Action 16 (fw BSX1)
32. Conclusion

Drive	NEC ND-3500A
Media	DVD		CD
Transfer Rate Write	+R	16x (9 - 22MBytes/sec)	-R	48x (3000-7200kBytes/sec)
	+R9	4x (5.5 MBytes/sec)
		2.4x (3.3 MByte/sec)
	+RW	8x (11 MBytes/sec)
			-RW	24x (3000-3600kBytes/sec)
	-R	16x ( 9 - 22MBytes/sec)
	-RW	6x (8.2MBytes/sec)
Transfer Rate Read		DVD-R 16x CAV (max 22000 kb/s)	CD-R 48x CAV (max 4800 kb/s)
		DVD+R 16x CAV (max 22000 kb/s)	CD-RW 16x CLV (max 2400 kb/s)
		DVD+R9 4X CLV (5500 KByte/s)
Mechanism	motorized Tray load mechanism for horizontal and vertical use
Interface	IDE / ATAPI
Burst Transfer Rate	PIO mode 4 / Ultra DMA 33
Cashe Memory	2MB
Audio	digital-out and line-out at the back (MPC compatible)
Modes supported	DVD-ROM, DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-Video, CD-ROM, CD-ROM XA, CD-Audio, CD Extra, CD Text, CD-IReady, CD-Bridge, Photo-CD, VideoCD, Hybrid CD
Writing methods	DAO(disc at once), SAO(session at once), TAO(track at once) with zero gap, variable or fixed packet, multisession
Compatibility	MPC Level 3, MultiRead, PC2001
Weight	1.01 kgr
Dimensions	148mm x 42mm x 190mm

- 4X DVD+R @ 8X

- 4X DVD-R @ 4X

- 8X DVD-R @ 8X ( TTG02)

- 8X DVD-R @ 8X ( RITEK G05)

- 8X DVD-R @ 8X ( CMC MAG AE1)

- 16X DVD+R @ 12X ( CMC MAG M01)

- Summary

Media	Code ID	Speed	Time
4X DVD+R	RICOHJPNR01	8X	9:35
4X DVD-R	RITEK G04	4X	14:25
8X DVD-R	TTG02	8X	9:48
8X DVD-R	RITEK G05	8X	9:47
8X DVD-R pr.	CMC MAG AE1	8X	9:49
16X DVD+R	CMC MAG M01	12X	7:04
