TEAC DV-W58G-A - Page 1

After the DV-W58G, TEAC decided to rise up the recording speed for the -R format due to the large competition, released its DV-W58G-A drive, supporting 8x for both +R and -R format and 4x for the RW. The drive is also a fast CD-R writer with the maximum writing speed of 40x. The full specifications for the DV-W58G-A drive are presented in the following table.

- Specifications

Interface	IDE/ATAPI
Buffer Size	2MB
Disc Diameter	12cm,8cm
Write Speed	DVD-R	8x(Z-CLV)
	DVD-RW	4x(CLV)
	DVD+R	8x(Z-CLV)
	DVD+RW	4x(CLV)
	CD-R	8x-40x(Partial CAV)
	US-RW	10x-24x(Partial CAV)
Read Speed	DVD+R/RW	2.5x-6x(CAV)
	DVD-R/RW	2.5x-6x(CAV)
	DVD-ROM ( single layer )	5.2x-12x(CAV)
	DVD-ROM ( dual layer)	3.5x-8x(CAV)
	CD-ROM / Finalized CD-R Data CD-DAE / Video CD	16x-40x(CAV)
	Finalized CD-RW	13x-32x(CAV)
Data Transfer Rate	Programmed I/O	16.6MB/s max.
	Burst DMA	16.6MB/s max.
	Burst UDMA	33.3MB/s max.
Disc rotation speed	8200rpm approx. (40x CAV, CD-ROM)
Applicable discs	DVD-ROM, DVD-Video, DVD±RW
	CD-ROM, CD-ROM-XA, CD-DA, Video-CD, Photo CD, CD-Extra, CD Plus, CD-Text, CD-R, CD-RW

Random Access Time	[DVD] 160ms Random stroke [CD] 160ms Random stroke
Ambient Temperature	Operating: 5 - 45^oC Non-Operating: -40 - 60^oC
Relative Humidity	Operating: 15- 80% (non-condencation) Non-Operating: 15 - 95% (non-condencation)
Power Requirements	+5V, +12V
MTBF	70,000POH ( duty 25%)
Dimensions	148.4W X 42.2H X 170D ( mm )
Mass ( Weight )	0.9Kg or less typ.

The drive uses 2MB buffer memory. RAW DAO 96 writing (CD) is supported, while Mount Rainier is not.

The TEAC DV-W58G-A uses the RPC II region control, allowing a user to change the drive's region at most 5 times. For our tests, we set the region code to 2 (Europe).
