Asus Announces The New P6TD Deluxe Motheboard

Asus Announces The New P6TD Deluxe Motheboard

PC components Jul 13,2009 0

Asus today announced the Xtreme Design series motherboards. Xtreme Design features Stack Cool3+ to enhance motherboard component longevity. It is a feature that was re-engineered from the original copper cooling innovation of the ASUS P5E64 WS motherboard. With the cooperation with Xtreme Design, Stack Cool3+ effectively cools motherboards with an enhanced PCB layer to provide a stable and low operating temperature for optimized data transmissions.

Xtreme Design features Xtreme phase to ensure stable and optimized power delivery; and Turbo V for a real-time, dynamic processing boost. Both features allow motherboard enthusiasts to experience optimal power performance under various loading conditions as well as a boost of up to 51% in processing throughput.



By passing stringent Electromagnetic Interference (EMI) testing that is 30% more rigorous than industry benchmarks; the new motherboards have exceptionally low EMI emissions. Together with a low Electrostatic Discharge (ESD) and an I/O bracket called Q-Shield, these features help to significantly reduce any negative health impact and potential damage to components.

ASUS Xtreme Design series of motherboards includes the P6TD Deluxe, an enhanced version of the X58-based P6T Deluxe motherboard.

Specifications:

Model: P6TD Deluxe
CPU: Intel Socket 1366 Core i7 Processor Extreme Edition/Core i7 Processor Supports Intel Dynamic Speed Technology
Chipset: Intel X58 / ICH10R
System Bus: Up to 6400 MT/s

Memory:
6 x DIMM, Max. 24 GB,
DDR3 2000(O.C.)*/1866(O.C.)*/1800(O.C.)*/1600(O.C.)/1333/1066
Non-ECC,Un-buffered Memory

Expansion slot:
3 x PCIe 2.0 x16 (at x16/x16/x1 or x16/x8/x8 mode)
1 x PCIe x4
2 x PCI

Multi-GPU:
Supports NVIDIA SLI Technology
Supports ATI CrossFireX Technology

Storage:
6 xSATA 3 Gb/s ports
1 xExternal SATA (SATA On-the-Go)
1 xUltraDMA 133/100/66 for up to 2 PATA devices

LAN: Dual Gigabit LAN controllers 2 Marvell88E8056 PCIe Gigabit LAN controller featuring AI NET2

Audio: ADI AD2000B 8 -Channel High Definition Audio CODEC

Other I/O ports:
1*PS/2, 1*eSATA, 1*IEEE1394a, 2*LAN, 8*USB, 1*Optical S/PDIF out, 1*Coaxial S/PDIF out

USB / IEEE1394a 14:
USB 2.0 ports /VIA VT6308 controller supports 1 x 1394a ports (one at mid-board; one at back panel)

Features:
StackCool3+, Turbo V, Xtreme Phase, 16+3 Phase Power design, Express Gate SSD, EPU, AI Nap, Wind-Flow Heat-pipe solution, Fan Xpert, Optional Fan for Water-cooling or Passive-Cooling only, Noise Filter, Q-Shield, Q-Connector, O.C. Profile, CrashFree BIOS 3, EZ Flash 2

Form Factor: ATX Form Factor, 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
