Pioneer DVR-109

Mar 3,2005 0

5. Protected Disc Tests



Review Pages

1. Introduction
2. Transfer Rate Reading Tests
3. CD Error Correction Tests
4. DVD Error Correction Tests
5. Protected Disc Tests
6. DAE Tests
7. Protected AudioCDs
8. CD Recording Tests
9. Writing Quality Tests - Clover System Tests
10. DVD Recording Tests
11. Official supported Media List v1.17
12. CDSpeed/PlexTools Scans - Page 1
13. CDSpeed/PlexTools Scans - Page 2
14. CDSpeed/PlexTools Scans - Page 3
15. CDSpeed/PlexTools Scans - Page 4
16. CDSpeed/PlexTools Scans - Page 5
17. CDSpeed/PlexTools Scans - Page 6
18. CDSpeed/PlexTools Scans - Page 7
19. CDSpeed/PlexTools Scans - Page 8
20. CDSpeed/PlexTools Scans - Page 9
21. Writing Quality Tests - Almedio AEC-1000
22. DVD+R DL - Page 1
23. DVD+R DL - Page 2
24. 109 vs SA300
25. Bitsetting
26. Conclusion



Pioneer DVR-109 Burner - Page 5

Protected Disc Tests

- Reading Tests

To create the image of the various protected titles to the hard disk, we used Alcohol 120% software and the appropriate settings, according to the protection type of the inserted discs. Below you can see the duration of each process as well as the transfer rate in each case.

Game Title
Protection Scheme
Duration
Reading speed
PSX "NBA Jam Extreme"
Lybcrypt
2:05 min
723 sectors/sec
Serious Sam The Second Encounter v1.07
SafeDisc v.2.60.052
58:03 min
96 sectors/sec
VRally II
SecuROM v.2
2:31 min
2277 sectors/sec

The reading performance of the drive with PSX games was average. The SafeDisc protection seems to be a minor issue for the Pioneer, as it is for the NEC. The performance with SecuROM was very good, and the Pioneer was the fastest among the drives.

- Writing Tests

The drive supports the DAO-RAW writing mode. For checking the drive's EFM correction status, we used 5 different game titles with different SafeDisc 2 versions having the latest software patches installed. After making the images of the various titles onto the hard disk, we burned them (at maximum speed) with Alcohol 120% v1.9.2.1705. Two different discs were created for each title; one with the "Bypass EFM error" enabled and one more with the function disabled.

  • Fifa 2004 - Safe Disc v3.1x
  • The Sims Superstar - Safe Disc v2.9x
  • The Sims Unleashed - Safe Disc v2.8x
  • Serious Sam Second Encounter - Safe Disc v2.51.021
  • Max Payne - Safe Disc v2.51.020

The table below shows the results of the attempted backups and whether they worked (game installed / played normally), or not.

Drive

Fifa 2004
SD v3.1

Sims Superstar SD v2.9
Sims Unleashed SD v2.8
Serious Sam-Second Encounter
SD v2.51.051
Max Payne
SD v2.51.020
EFM OFF
EFM ON
EFM OFF
EFM ON
EFM OFF
EFM ON
EFM OFF
EFM ON
EFM OFF
EFM ON
Toshiba
SD-M1502
No
Yes
Creative CD5233E

Pioneer DVR-109

The drive can backup accurately only up to SD v2.51.201, due to the used chipset. The newer builds cannot be replicated accurately, either with EFM Correction option or without.
