Following the introduction of the XH97V and SH97R6 barebone PC models that have been prepared for the fifth generation of Intel Core processors, Shuttle today introduced its first barebone PC with a built-in Broadwell processor. As a successor to the DS47 and DS437 models, the DS57U also belongs to the 1 litre PC class. The DS57U is delivered as a barebone PC and includes the case, motherboard, cooling system and power supply unit as its core components as standard.
The system is powered by a pre-nstalled Intel Celeron 3205U dual-core processor (2x 1.5 GHz), which also is part of the delivery. The 14-nm architecture and power consumption of less than 15 W promise low energy costs together with improved performance.
The fanless DS57U not only works quietly, it is almost maintenance-free, as the passive cooling ensures that no dust is sucked into the machine.
Once the two screws on both covers of the steel case are undone, space for one 2.5" hard drive or SSD drive and two SO-DIMM sockets with a capacity for up to 16 GB of DDR3L memory comes to light. One Mini-PCI Express slot (full-size) is available for additional expansions, e.g. an mSATA module. A second Mini-PCI Express slot (half-size) comes already fitted with a WLAN module.
With its slim dimensions of 20 x 3.95 x 16.5 cm (DWH), the DS57U as the first Shuttle barebone sports two Intel Gigabit Ethernet interfaces. Plus, 2x USB 3.0, 1x DisplayPort, 1x HDMI and audio ports can be found. Also at the rear side of the machine sits a multi-pin connector for remote power-on (e.g. in the case of fixed installation in an awkward position). The front panel unveils a card reader, four USB 2.0 ports and two RS-232 interfaces for connecting peripheral devices.
The recommended retail price for the Shuttle Barebone DS57U is EUR 192.00 (ex VAT). It is available from specialist retailers Europe-wide as of now.
